SHANLING H5 Dual AK4493SEQ MQA DAC Hi-Res Portable Headphone Amplifier

Experience the exquisite tones of AKM's AK4493SEQ DAC chips in Shanling H5, delivering clear audio with high SNR and low distortion. The dual DAC setup ensures exceptional performance in decoding high-resolution signals.

Heart of the Tiger - AK4493SEQ DAC Marvel: With two AK4493SEQ DAC chips, H5 achieves an SNR >121dB, 768kHz/32bit sampling rate, and minuscule THD+N at 0.0004%. The inclusion of XU316 ensures DSD512 decoding and full MQA support for uncompromised audio excellence.

Cutting-Edge USB Processor & Expandable Storage: Benefit from XMOS's 16-core XU316 USB processor, allowing support for high-resolution 32-Bit/768kHz PCM and native DSD on the H5. Expand your music library with a microSD card slot, accommodating up to 2TB. Manage it effortlessly with the Eddict player app.

New Op-amp Audio Architecture: Embrace a smoother soundstage with the latest op-amp architecture featuring TPA6120A2 and OPA1612 chips. The third-gen USB decoding chip, XU316, supports DSD512 decoding and MQA Full Decoder, ensuring precision in digital signal transmission.

Dual Headphone Output & Three-Level Gain: Shanling H5 caters to both single-ended and balanced headphones, supporting three gain modes. Output up to 840mW@32Ω through the balanced 4.4mm port and 227mW through the 3.5mm output. Enjoy versatility without compromising on power.

Display and Bluetooth Convenience: Navigate through settings with ease using the 0.87" display screen and LED indicators. Embrace wireless freedom with high-resolution Bluetooth input supporting LDAC, AAC, and SBC. MQA certification adds another layer of audio fidelity. The H5's colorful indicators not only signify different sampling rates but also add a touch of visual elegance, making your listening sessions more engaging.

Long-Lasting Battery & Durable Build: Carry your music companion anywhere with a 3500mAh battery, delivering up to 12.5 hours of playtime. Benefit from QC3.0 18W fast charging for quick top-ups. Crafted from aircraft-grade magnesium-aluminum alloy, the H5 boasts a lightweight yet robust build for stability and durability.

Specifications:
Size: 102*85*25(mm)
Weight: 270.4g
Screen: 0.87’OLED
Audio Format Support: ISO / DXD / APE / FLAC / WAV / AIFF / AlF / DTS / MP3 / WMA / AAC / OGG / ALAC / MP2 / M4A / AC3 / M3U / M3U8 / OPUS / DSD (".iso", ".dsf", ".dff") *dst not supported
MQA Support: MQA Full Decoder
Decoding Output: 768kHz/32 bit, DSD512
MicroSD Output: 384 KHz/32 bit, DSD256
Frequency Compensation: High, Middle, Low
DAC chips: AK4493SEQ*2
Digital Filters: Six different types of filters
Bluetooth: 5.0
Bluetooth Reception Support: LDAC/SBC/AAC (*Bluetooth can only receive, not support transmit.)
Output power
PO: 2.7V@32Ω(227mW@32Ω)
BAL: 5.19V@32Ω(840mW@32Ω)
Frequency: 20Hz-40kHz(-0.7dB)
THD+N
PO: 0.0014%@32Ω(A-Weight@0.3V)
BAL: 0.0004%@32Ω(A-Weight@1V)
Dynamic
PO: 118dB@32Ω(A-Weight)
BAL: 121@32Ω(A-Weight)
Channel
PO: 80dB@32Ω
BAL: 105dB@32Ω
SNR
PO: 118dB@32Ω(A-Weight)
BAL: 121@32Ω(A-Weight)
