XDUOO MT02 Hybrid Tube Headphone Amplifier with Dual 6J1 Tubes

XDUOO MT02 Hybrid Tube Headphone Amplifier

The XDUOO MT02 is a desktop hybrid tube headphone amplifier that pairs dual 6J1 vacuum tubes with a transistor-based Class-A output stage, delivering a tube-forward presentation of warmth, detail, and driving power. With 4.4mm balanced and 6.35mm headphone outputs, adjustable gain, pre-out functionality, and a compact aluminum chassis with transparent acrylic panels, it suits a wide range of headphones and systems.

Hybrid Tube-Transistor Design

The MT02 uses a hybrid amplifier topology that pairs dual 6J1 tubes in the voltage gain stage with a transistor-based Class-A output stage. This delivers the smooth tonal character and rich midrange of vacuum tubes while providing the current delivery and control needed to drive demanding headphones.

Dual 6J1 Vacuum Tube Stage

Two 6J1 vacuum tubes work in the preamplification stage, contributing warmth, natural vocals, and smooth high frequencies. The tube stage preserves musical detail while creating a relaxed, fatigue-free listening character that complements both modern and classic recordings.

Class-A Output Power

The transistor-based Class-A amplification stage delivers up to 1,500mW into a 32Ω load, powering everything from efficient portable headphones to higher-impedance designs. High current delivery, fast transient response, and controlled bass maintain clarity across dynamic passages.

Balanced & Single-Ended Outputs

Front-panel 4.4mm balanced and 6.35mm single-ended headphone outputs provide compatibility with today’s most common headphone connections. A selectable high and low gain switch makes it easier to match output levels with different headphone sensitivities.

Pre-Out for System Integration

The integrated pre-out lets the MT02 function as a tube preamplifier for external amplifiers or powered speakers. Volume stays synchronized through the front-panel control, making it easy to integrate into a desktop or two-channel listening system.

Premium Components & Protection

ELNA audio coupling capacitors and Rubycon filter capacitors support low noise and stable performance. An intelligent relay protection system introduces a 30-second startup delay for tube warm-up, minimizes power-on/off pop noise, and provides overload and short-circuit protection for both the amplifier and connected headphones.

Specifications

• Amplifier Type: Hybrid tube-transistor Class-A headphone amplifier
• Tube Complement: Dual 6J1 vacuum tubes
• Power Supply: DC 12V / 2A
• Output Power (32Ω): 1,500mW
• Output Power (75Ω): 900mW
• Output Power (100Ω): 700mW
• Output Power (150Ω): 500mW
• Output Power (250Ω): 300mW
• Output Power (300Ω): 250mW
• Output Power (600Ω): 130mW
• Frequency Response: 10Hz–60kHz (±0.5dB)
• Gain: +12dB / +18dB
• THD+N: ≤0.1% (1kHz @ 32Ω)
• Signal-to-Noise Ratio: 118dB
• Crosstalk: ≥73dB
• Headphone Outputs: 4.4mm balanced + 6.35mm single-ended
• Pre-Out: Yes (synchronized volume)
• Dimensions (W×H×D): 136 × 110 × 81 mm
• Weight: 0.61 kg

What's Included

• XDUOO MT02 headphone amplifier
• Two preinstalled 6J1 vacuum tubes
• 12V DC power supply
• User documentation
